ヒューズの溶断過程におけるヒューズエレメントの温度分布制御による遮断特性の改善

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2019/11/01

タイトル(英語): Improvement of Current Breaking Performance in the Fuse by Controlling the Temperature Distribution of the Fuse Element during Pre-arcing Process

著者名: 若宮　将（埼玉大学 理工学研究科），大月　翔平（埼玉大学 理工学研究科），山納　康（埼玉大学 理工学研究科）

著者名(英語): Masaru Wakamiya (Saitama University), Shohei Otsuki (Saitama University), Yasushi Yamano (Saitama University)

キーワード: ヒューズエレメント，ヒューズ，アーク放電，アーク電圧，温度分布制御　　fuse element，fuse，arc discharge，arc voltage，temperature distribution control

要約(英語): This paper describes improvements of current breaking performance in fuse-link by controlling the temperature distribution of the fuse element during pre-arcing process. The fuse element is designed and produced to obtain the simultaneous arc-forming of several interrupting points in the fuse element by controlling the temperature of the interruption point in consideration of the heat generation by current flowing and heat radiation to the surrounding media. The interruption test was carried out to evaluate the current breaking performance. It was confirmed that the current breaking performance of the fuse which controlled temperature distribution was improved in comparison with common structure fuses without temperature controls. Also, it was found that this control method can be applied to fuses of different pattern and thicknesses. In addition, the interruption performance could be improved for different currents conditions used for calculation.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.139 No.11 （2019） 特集：電磁界解析などの大規模数値計算技術

本誌掲載ページ: 707-712 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/139/11/139_707/_article/-char/ja/
