打抜き加工による塑性変形の影響を考慮した渦電流損補正係数に基づくIPMモータの鉄損解析

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2019/12/01

タイトル(英語): Iron Loss Estimation for IPM Motors based on Eddy Current Loss Correction Factor Considering Plastic Deformation by Punching

著者名: 吉岡　卓哉（（株）デンソー／同志社大学 理工学部 電気工学科），髙橋　康人（同志社大学 理工学部 電気工学科），藤原　耕二（同志社大学 理工学部 電気工学科）

著者名(英語): Takuya Yoshioka (DENSO CORP./Department of Electrical Engineering, Doshisha University), Yasuhito Takahashi (Department of Electrical Engineering, Doshisha University), Koji Fujiwara (Department of Electrical Engineering, Doshisha University)

キーワード: 後処理鉄損計算法，プレイモデル，一次元渦電流解析，異常渦電流損，IPMモータ　　post-processing for iron loss estimation，play model，1-D eddy current analysis，excess loss，IPM motor

要約(英語): To estimate iron loss in interior permanent magnet (IPM) motors driven by PWM inverters accurately, 1-dimensional finite-element analyses for a silicon steel sheet in the thickness direction considering hysteretic property and skin effect were proposed. However, the method cannot directly consider so-called excess loss. To express the excess loss, the eddy current loss correction factor is introduced into the method and the basic property of the factor under sinusoidal excitation has been investigated. In this paper, we investigate the property of the factor for plastic deformation assumed for press working. Finally, we apply the iron loss estimation method to the IPM motors and discuss the contribution of eddy-current, hysteresis and excess losses.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.139 No.12 （2019）

本誌掲載ページ: 767-775 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/139/12/139_767/_article/-char/ja/
