新しい高信頼性プロセスバスを適用した保護リレーシステムの検証（第2報）

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/02/01

タイトル(英語): Verification of a New Protection Relay System based on High Reliable Process Bus―Part 2

著者名: 伊藤　拓也（中部電力（株）），冨田　恒夫（中部電力（株）），戸井　雅則（富士電機（株）），長谷川　俊（富士電機（株）），板垣　大樹（東芝エネルギーシステムズ（株）），岡井　誠（東芝エネルギーシステムズ（株）），清水　利憲（三菱電機（株）），岩丸　明史（三菱電機（株））

著者名(英語): Takuya Ito (Chubu Electric Power Co., Inc.), Tsuneo Tomida (Chubu Electric Power Co., Inc.), Masanori Toi (Fuji Electric Co., Ltd.), Shun Hasegawa (Fuji Electric Co., Ltd.), Daiju Itagaki (Toshiba Energy Systems & Solutions Corporation), Makoto Okai (Toshiba Energy Systems & Solutions Corporation), Toshinori Shimizu (Mitsubishi Electric Corporation), Akifumi Iwamaru (Mitsubishi Electric Corporation)

キーワード: IEC 61850，プロセスバス，オーバーサンプリング，時刻同期，電流差動リレー，3サイクルしゃ断　　IEC 61850，process bus，over sampling，time synchronization，current differential protection，3 cycle time breaking

要約(英語): The IEC 61850 based process bus system on a substation automation system is currently being verified in the world. Some typical IEC 61850 based process bus system contains “Sampled value” communication function and it requires the high accuracy time synchronization scheme to get sampling timing simultaneity in each merging unit. Authors surveyed the way of improving the process bus system, and focused to renovate availability of the time synchronization scheme for getting sampling timing that often used IEC 61588 “Precision Clock Synchronization Protocol” complied special network communication equipment and technics. This paper introduces a new process bus scheme using over sampling technology and new communication network using high reliable optical fiber splitter to as the renovation way. This paper also describes an example of verification test result to confirm the usability, e. g. the AC electricity measurement test to survey accuracy and current differential protection relay test to survey the real-time characteristic. Finally, this paper concludes the availability of this process bus system concept.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.140 No.2 （2020）　特集：令和元年電力・エネルギー部門大会

本誌掲載ページ: 49-56 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/2/140_49/_article/-char/ja/
