Synthesis of Equivalent Circuit from Homogenized FE Equation using Model Order Reduction

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/02/01

タイトル(英語): Synthesis of Equivalent Circuit from Homogenized FE Equation using Model Order Reduction

著者名: Shingo Hiruma (Graduate School of Information Science and Technology, Hokkaido University), Hajime Igarashi (Graduate School of Information Science and Technology, Hokkaido University)

著者名(英語): Shingo Hiruma (Graduate School of Information Science and Technology, Hokkaido University), Hajime Igarashi (Graduate School of Information Science and Technology, Hokkaido University)

キーワード: complex permeability，equivalent circuit，model order reduction，multi-scale problem

要約(英語): This paper introduces a novel method for synthesis of the equivalent circuit of an electromagnetic system described by a homogenized FE equation via model order reduction. The homogenization method replaces fine-structured material such as multi-turn coils, soft magnetic composite and laminated iron sheets with uniform material with complex permeability. The present method reduces the FE equation including the complex permeability to a circuit equation for small variables which can be solved with small computational cost. The present method is effective for time-domain analysis and makes it possible to consider magnetic saturations.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.140 No.2 （2020）　特集：令和元年電力・エネルギー部門大会

本誌掲載ページ: 134-139 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/2/140_134/_article/-char/ja/
