直列抵抗を考慮した送電線サージ特性近似式

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/04/01

タイトル(英語): Approximate Formulas for Surge Characteristics on the Transmission Line considering Series Resistance

著者名: 関岡　昇三（湘南工科大学 電気電子工学科）

著者名(英語): Shozo Sekioka (Department of Electrical and Electronic Engineering, Shonan Institute of Technology)

キーワード: 分布定数線路，サージ，直列抵抗，送電線　　distributed-parameter line，surge，series resistance，transmission line

要約(英語): The series resistance of a transmission line in high frequency phenomena such as lightning surge becomes high due to the skin effect, and affects switching and lightning overvoltages in an electric power system. A number of transmission line models have been proposed to consider the frequency dependence of line constants. It is difficult to denote surge characteristics of a transmission line in time domain due to the existence of the series resistance. This paper proposes approximate formulas for terminal voltages on the transmission line in time domain. The approximate formulas are derived on the basis of the lattice diagram method. The expression of the approximate formulas is given by exponential functions, and is very simple. The formulas are useful for engineers to discuss many parameters and to understand simulation results for transmission line having high series resistance.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.140 No.4 （2020） 特集：最近の電線・ケーブル技術

本誌掲載ページ: 343-349 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/4/140_343/_article/-char/ja/
