IEC 61131-3/IEC 61850準拠PLCによる保護制御機能の実装手法

IEC 61131-3/IEC 61850準拠PLCによる保護制御機能の実装手法

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/05/01

タイトル(英語): An Implementation Method for the Protection and Control Functions Defined in IEC 61850 with PLC based on IEC 61131-3

著者名: 坂 泰孝((一財)電力中央研究所),上田 紀行((一財)電力中央研究所),大谷 哲夫((一財)電力中央研究所)

著者名(英語): Yasutaka Saka (Central Research Institute of Electric Power Industry), Noriyuki Ueda (Central Research Institute of Electric Power Industry), Tetsuo Otani (Central Research Institute of Electric Power Industry)

キーワード: PLC,論理ノード,データオブジェクト,受電自動切替,線路検圧,国際規格  programmable logic controller,logical node,data object,automatic transfer between two sources,voltage presence indicator,international standard

要約(英語): Introducing commercially available Intelligent Electronic Devices (IED) based on IEC 61850 tends to increase in Japan. Whereas, PLCs based on IEC 61131-3/IEC 61850 have been appearing, which are capable of programming control logic of logical nodes and data object. This paper proposes an implementation method of protection and control functions by using the programming languages specified in IEC 61131-3. It also shows some functions implemented according to the proposed method meet the functions' requirements.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.140 No.5 (2020) 特集:電力需給解析標準モデル(IEEJ AGC30)を使ったシミュレーション技術

本誌掲載ページ: 395-401 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/5/140_395/_article/-char/ja/
