均質化有限要素法を用いた多重巻き楕円断面コイルの時間領域解析

均質化有限要素法を用いた多重巻き楕円断面コイルの時間領域解析

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/05/01

タイトル(英語): Time-Domain Finite Element Analysis of Multi-turn Coil with Elliptic Cross Section using based on Homogenization Method

著者名: 藤田 祥伍(北海道大学 情報科学研究科 システム情報科学専攻 システム融合情報学講座 電磁工学研究室),五十嵐 一(北海道大学 情報科学研究科 システム情報科学専攻 システム融合情報学講座 電磁工学研究室)

著者名(英語): Shogo Fujita (Applied Electromagetics Lab., Research Group of Informatics for System Synthesis, Division of Systems Science and Informatics, Graduate School of Information Science and Technology, Hokkaido University), Hajime Igarashi (Applied Electromagetics Lab., Research Group of Informatics for System Synthesis, Division of Systems Science and Informatics, Graduate School of Information Science and Technology, Hokkaido University)

キーワード: 均質化,楕円断面コイル,表皮効果・近接効果,テンソル型実効透磁率,RC法  homogenization,multi-turn coil with elliptic cross-section,skin and proximity effects,tensor-type complex permeability,recursive convolution (RC) scheme

要約(英語): In this paper, a homogenized finite element method for transient analysis of electric apparatus including a multi-turn coil with elliptic cross-section. The tensor-type complex permeability of the multi-turn coil is expanded into partial fractions, which can then be transformed into time-domain. The convolution integral is effectively evaluated using the RC method which does not need large memory storage. It is shown that the power computed by the proposed method is in good agreement with that computed by the conventional finite element method without homogenization.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.140 No.5 (2020) 特集:電力需給解析標準モデル(IEEJ AGC30)を使ったシミュレーション技術

本誌掲載ページ: 402-408 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/5/140_402/_article/-char/ja/
