送電損失低減を目的としたPV連系送電系統における2電圧階級のVQC装置協調運用決定手法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/06/01

タイトル(英語): Operation of Voltage Reactive Power Control Devices based on Cooperation between Two-Voltage Class Transmission Network with PV Systems to Reduce Power Loss

著者名: 金子　曜久（早稲田大学 先進理工学研究科 電気・情報生命専攻），芳澤　信哉（早稲田大学 先進理工学研究科 電気・情報生命専攻），林　泰弘（早稲田大学 先進理工学研究科 電気・情報生命専攻），杉村　修平（（株）明電舎），植田　喜延（（株）明電舎），田邊　隆之（（株）明電舎）

著者名(英語): Akihisa Kaneko (Graduate School of Advanced Science and Engineering, Major in Electrical Engineering and Bioscience, Waseda University), Shinya Yoshizawa (Graduate School of Advanced Science and Engineering, Major in Electrical Engineering and Bioscience, Waseda University), Yasuhiro Hayashi (Graduate School of Advanced Science and Engineering, Major in Electrical Engineering and Bioscience, Waseda University), Shuhei Sugimura (Meidensha Corporation), Yoshinobu Ueda (Meidensha Corporation), Takayuki Tanabe (Meidensha Corporation)

キーワード: 電圧無効電力制御，送電損失，最適潮流計算，タブーサーチ，太陽光発電システム，送電系統　　voltage reactive power control (VQC)，power loss，optimal power flow，tabu-search，photovoltaic system，transmission network

要約(英語): Transmission system operators (TSO) are responsible to manage the power quality within a proper range and to reduce power loss. Voltage reactive power control (VQC) is mainly utilized to manage the power flow. In the conventional VQC scheme, the static condenser (SC) and shunt reactor (ShR) is generally adjusted based on the target value determined for the heavy load condition in each voltage class. On the other hand, the installation of the massive photovoltaic (PV) systems into transmission systems cause the complex power flow such as the short-term fluctuation of power flow and reverse power flow from the lower transmission system to the upper transmission system. Thus, in the future power system with PV systems, the target values of the VQC devices need to be updated in the short-time period considering the interaction between the upper and lower transmission system to manage the power quality and to the reduce power loss efficiently. This paper proposes the optimization methodology for VQC devices in two-voltage class of transmission system using tabu-search and optimal power flow based on the central VQC methodology. To verify the effectiveness of the proposed methodology, the numerical simulation was performed based on the revised IEEJ EAST 30-machine system model.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.140 No.6 （2020） 特集：電力系統の電圧運用・制御技術

本誌掲載ページ: 484-494 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/6/140_484/_article/-char/ja/
