直撃雷に対する高圧配電線雷事故率の総合評価―フラッシオーバおよび避雷器処理エネルギーの評価プログラム―

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2022/02/01

タイトル(英語): Assessment Program of Direct Lightning Performance for Medium Voltage Distribution Lines―Evaluation of Flashover and Surge Arrester Absorption Energy―

著者名: 石本　和之（（一財）電力中央研究所 グリッドイノベーション研究本部）

著者名(英語): Kazuyuki Ishimoto (Grid Innovation Research Laboratory, CRIEPI)

キーワード: 配電線，直撃雷，雷事故率計算，フラッシオーバ，避雷器処理エネルギー　　distribution lines，direct lightning，lightning outage calculation，flashover，absorption energy of surge arrester

要約(英語): In Japan, with the progress of lightning protection measures, lightning outages associated with indirect lightning are less frequent, and direct lightning is the main cause of lightning outages. To achieve an effective lightning protection design for medium voltage distribution lines considering cost performance, it is necessary to evaluate the lightning outage rate for each equipment configuration. As for this purpose, we have developed the lightning outage calculation program for medium voltage distribution lines due to direct lightning. The developed program can estimate not only the flashover rate of insulators and the absorption energy exceeding probability of surge arresters, which have been studied in previous studies, but also the flashover rate between the phase conductors and the energy absorption history of the surge arresters which have not been studied enough. In this paper, we show the outline of the developed program and some examples of calculation results.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.142 No.2 （2022） 特集：令和3年電力・エネルギー部門大会

本誌掲載ページ: 98-105 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/142/2/142_98/_article/-char/ja/
