高圧配電線の構成が直撃雷による相間スパークオーバ発生率に与える影響

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2022/02/01

タイトル(英語): Influence of Medium Voltage Distribution Line Configuration on Phase to Phase Sparkover Rate due to Direct Lightning Strike

著者名: 山口　宜大（（一財）電力中央研究所 グリッドイノベーション研究本部），石本　和之（（一財）電力中央研究所 グリッドイノベーション研究本部），森　亮太（（一財）電力中央研究所 グリッドイノベーション研究本部），河野　丈治（（一財）電力中央研究所 グリッドイノベーション研究本部）

著者名(英語): Nobuhiro Yamaguchi (Grid Innovation Research Laboratory, CRIEPI), Kazuyuki Ishimoto (Grid Innovation Research Laboratory, CRIEPI), Ryota Mori (Grid Innovation Research Laboratory, CRIEPI), Jyoji Kawano (Grid Innovation Research Laboratory, CRIEPI)

キーワード: 高圧配電線，径間途中断線，相間スパークオーバ発生率，架空地線　　medium voltage distribution lines，wire breaking at mid-span，phase to phase sparkover rate，overhead ground wires

要約(英語): In recent years, to reduce maintenance and management cost of distribution facilities, overhead ground wires are sometimes removed in a certain area. In such distribution lines, wire breaking at mid-span due to direct lightning is of concern. Although phase to phase sparkover is considered to be one of the factors of wire breaking at mid-span, its quantitative study has not yet been carried out. In this paper, at first, we experimentally examined detailed sparkover characteristics between phase conductors against short tail lightning impulse voltage, which is assumed to be phase to phase voltage. Next, based on experimental results, we estimate the phase to phase sparkover rate by means of lightning outage calculation program developed by CRIEPI. Estimated results suggest the phase to phase sparkover rate depends on the configuration of distribution lines, such as span length, arrangement of conductors, and so forth.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.142 No.2 （2022） 特集：令和3年電力・エネルギー部門大会

本誌掲載ページ: 114-120 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/142/2/142_114/_article/-char/ja/
