方形断面洞道に布設されたケーブルの線路定数計算手法の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2022/02/01

タイトル(英語): Development of a Method for Calculating the Transmission-Line Constants of Cables Installed in a Rectangular Tunnel

著者名: 田中　洋平（（一財）電力中央研究所 グリッドイノベーション研究本部），米澤　力道（（一財）電力中央研究所 グリッドイノベーション研究本部），野田　琢（（一財）電力中央研究所 グリッドイノベーション研究本部）

著者名(英語): Yohei Tanaka (Grid Innovation Research Laboratory, CRIEPI), Rikido Yonezawa (Grid Innovation Research Laboratory, CRIEPI), Taku Noda (Grid Innovation Research Laboratory, CRIEPI)

キーワード: 洞道布設ケーブル，方形洞道，線路直列インピーダンス，線路並列アドミタンス，サージインピーダンス　　cables installed in a tunnel，rectangular tunnel，series impedance，shunt admittance，surge impedance

要約(英語): Accurately calculating the transmission-line constants of underground cables is important for various types of power system simulations such as electromagnetic transient, power flow, and transient stability simulations. The transmission-line constants of cables installed in a tunnel must be calculated taking the skin and proximity effects into account, since the cables are spaced closely to each other and also to a wall face of the tunnel. However, the conventional method, which is capable of considering the skin and proximity effects, has been restricted to circular cross-section conductors such as cables and a circular tunnel. Therefore, the method cannot handle a tunnel with a rectangular cross section. In this paper, a method for calculating the transmission-line constants of a conductor system in which both circular and rectangular cross-section conductors present in the same space is proposed. Then, the walls of a rectangular tunnel are represented by eight rectangular conductors, and cables represented by circular conductors are placed inside the eight rectangular conductors. In this paper, the proposed method is verified by experiments using a conductor system in which three circular conductors are arranged in a rectangular conductor. Calculated results obtained by the proposed method agree well with the measured results.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.142 No.2 （2022） 特集：令和3年電力・エネルギー部門大会

本誌掲載ページ: 128-138 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/142/2/142_128/_article/-char/ja/
