遮断器の開閉衝撃による部品損傷の評価手法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2023/02/01

タイトル(英語): Evaluation Method of Component Damage due to Switching Operation Impact of Circuit Breakers

著者名: 富安　邦彦（（株）日立製作所 研究開発グループ），佐藤　隆（（株）日立製作所 研究開発グループ），外崎　博教（（株）日立産機システム），藪　雅人（（株）日立産機システム）

著者名(英語): Kunihiko Tomiyasu (Research and Development Group., Hitachi, Ltd.), Takashi Sato (Research and Development Group., Hitachi, Ltd.), Hironori Tonosaki (Hitachi Industrial Equipment Systems Co., Ltd.), Masato Yabu (Hitachi Industrial Equipment Systems Co., Ltd.)

キーワード: 真空遮断器，開閉衝撃，損傷　　vacuum circuit breaker，switching operation impact，damage evaluation

要約(英語): The scope of application of vacuum circuit breakers is being expanded as an environment-friendly electric power device for carbon neutrality. Since the energy of the actuator increases as with the breaking capacity increases, it is important to properly evaluate the mechanical durability due to the switching operation impact in order to improve the reliability of the product. Accordingly, this research devised a method for evaluating component damage due to switching operation impact. It is necessary to evaluate the influence of switching operation impact on component damage by considering the frequency of the impact acceleration not only by the peak value of the acceleration. Evaluation by the damage boundary curve defined by the maximum acceleration and the velocity change of the component is applicable. By applying this method, it is possible to prevent damage to circuit breaker components and avoid cost increase due to overdesign.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.143 No.2 （2023） 特集：令和4年電力・エネルギー部門大会

本誌掲載ページ: 176-179 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/143/2/143_176/_article/-char/ja/
