配電用変電所保護リレーシステムの変遷と課題

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2023/06/01

タイトル(英語): Transition and Issues of Substation Protection Relay Systems for Power Distribution

著者名: 天雨　徹（中部電力パワーグリッド（株）送変電部）

著者名(英語): Toru Amau (Chubu Electric Power Grid Co., Lnc.)

キーワード: 配電線短絡保護，配電線地絡保護，IEC 61850，N-1電源制御，レトロフィット，電圧制御　　distribution line short-circuit protection，distribution line earth fault protection，IEC 61850，N-1 inter trip scheme，retrofit，voltage regulation

要約(英語): In June 2023, the Protection Relay System Technical Committee planned a special issue labeled as “Protection Relay System Technology in Power Distribution Stations”. Protection relay systems play a vital role in the stable operation of power systems. In recent years, they have also been responsible for solving various problems in power systems, such as the realization of mass introduction of renewable energy, expansion of the operational capacity of power distribution facilities, and rationalization of facility configuration. The following topics were gathered and discussed as a result of the call for this special issue.: (1) Proposals for distribution line protection methods (short circuit protection, ground fault protection), (2) Case studies using IEDs (IEC 61850), N-1 inter trip scheme, bus bar protection relays, and comprehensive retrofits, (3) Optimizing accident recovery during distribution line accidents, (4) Voltage adjustment methods using storage battery capacity operation, (5) Bank Recorder and switchboard configuration when dealing with reverse power flow. A total of 10 papers were submitted. This commentary touches on the contents of the technical reports as an aid to understanding these papers. It also outlines the history of distribution substation protection relays and the latest technology in distribution substation protection relay systems.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.143 No.6 （2023） 特集：配電用変電所保護リレーシステムをはじめとした保護リレーシステム技術

本誌掲載ページ: 310-315 p

原稿種別: 解説／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/143/6/143_310/_article/-char/ja/
