配電系統の対地静電容量増加を考慮した配電線地絡保護システム

配電系統の対地静電容量増加を考慮した配電線地絡保護システム

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2023/06/01

タイトル(英語): Earth Fault Protection System for Distribution Lines Considering the Increase of Capacitance to Earth of Distribution System

著者名: 林田 弘太郎(名古屋工業大学大学院 工学研究科),青木 睦(名古屋工業大学大学院 工学研究科),天雨 徹(中部電力パワーグリッド(株)送変電部),大谷 哲夫((一財)電力中央研究所 グリッドイノベーション研究本部),小澤 辰哉(名菱電子(株)システム設計一課),對馬 宏介(名菱電子(株)システム設計一課)

著者名(英語): Kotaro Hayashida (Nagoya Institute of Technology), Mutsumi Aoki (Nagoya Institute of Technology), Toru Amau (Chubu Electric Power Grid Co., Inc.), Tetsuo Otani (Central Research Institute of Electric Power Industry), Tatsuya Ozawa (Meiryo Denshi), Kosuke

キーワード: 配電系統,地絡保護,対地静電容量,残留電圧,IED  power distribution system,earth fault protection,capacitance to earth,residual voltage,IED

要約(英語): The increase of capacitance to earth of distribution system would make it difficult for the conventional earth fault protection system for distribution lines to locate and isolate an earth fault. Therefore, the authors propose a new method in consideration of the increase of capacitance to earth. The proposed method combines three relays with different protectable ranges to detect an earth fault. Specifically, earth faults are detected by measuring zero-phase voltage, zero-phase current, and residual voltage. In addition, the use of both zero-phase voltage and line-to-line voltage ensures the selection of the fault line. This paper clearly shows the usefulness of the proposed system by graphing the protectable range of each protection relay. In addition, this paper implements the proposed system using IEDs, which are general-purpose protective relay devices and reports the results of the verification test by Real Time Simulator.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.143 No.6 (2023) 特集:配電用変電所保護リレーシステムをはじめとした保護リレーシステム技術

本誌掲載ページ: 338-347 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/143/6/143_338/_article/-char/ja/
