短時間フリッカ測定機能を備えたバンク逆潮流事故記録装置の配備とその計測事例

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2023/06/01

タイトル(英語): Introduction of Installation and Measurement Cases of the Recorder for Detection and Recording Power System Fault during Reverse Power Flow on Transformer with the Function Detecting and Recording Voltage Flicker that Changes in a Short Time

著者名: 飯干　憲志（九州電力送配電（株）系統技術本部），伊藤　清太（九州電力送配電（株）系統技術本部），山口　保孝（（株）近計システム 電力システム事業部），上田　順一（（株）近計システム 電力システム事業部），藤内　重良（（株）近計システム 電力システム事業部）

著者名(英語): Kenshi Iihoshi (Kyushu Electric Power CO., INC.), Seita Ito (Kyushu Electric Power CO., INC.), Yasutaka Yamaguchi (KINKEI SYSTEM CORPORATION), Junichi Ueda (KINKEI SYSTEM CORPORATION), Shigeyoshi Fujiuchi (KINKEI SYSTEM CORPORATION)

キーワード: 再生可能エネルギー，バンク逆潮流，電圧フリッカ，単独運転検出機能，ハンチング現象　　renewable energy，reverse power flow on transformer，voltage flicker，islanding detection，hunting phenomenon

要約(英語): With the increase in the amount of interconnection of renewable energy, a transformer reverse power flow has occurred. In the past, transformer reverse power flow was restricted, but with the revision of the law in May 2013, it has permitted to operate the system on the premise of transformer reverse power flow by installing the necessary protection device. Along with this, the bank reverse power flow fault recorder is installed at the distribution substation for power system failure recording and analyzing at the time of transformer reverse power flow. On the other hand, the occurrence of voltage flicker phenomenon due to renewable energy has become a problem in recent years. This voltage flicker has the property of changing rapidly, and it is difficult to measure with the conventional ΔV10 flicker meter. Therefore, we implemented a short-time flicker measurement function that can measure voltage flicker with rapidly changing in the bank reverse power flow fault recorder. The outline and measurement examples are introduced.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.143 No.6 （2023） 特集：配電用変電所保護リレーシステムをはじめとした保護リレーシステム技術

本誌掲載ページ: 357-363 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/143/6/143_357/_article/-char/ja/
