配電線スリム化を目的としたダイナミックレーティング適用時の蓄電池設備容量評価
配電線スリム化を目的としたダイナミックレーティング適用時の蓄電池設備容量評価
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2023/06/01
タイトル(英語): An Evaluation of Capacity of Storage Battery for Streamlining Distribution Lines according to Dynamic Rating
著者名: 石田 匠輝(名古屋工業大学 大学院工学研究科/中部電力パワーグリッド(株)),中村 勇太(名古屋工業大学 大学院工学研究科),青木 睦(名古屋工業大学 大学院工学研究科),彦山 和久(中部電力パワーグリッド(株)),野々山 公亮(中部電力パワーグリッド(株))
著者名(英語): Naruki Ishida (Nagoya Institute of Technology/Chubu Electric Power Grid Co., Inc.), Yuta Nakamura (Nagoya Institute of Technology), Mutsumi Aoki (Nagoya Institute of Technology), Kazuhisa Hikoyama (Chubu Electric Power Grid Co., Inc.), Tomoaki Nonoyama (C
キーワード: 配電系統,配電線スリム化,蓄電池,運用計画,ダイナミックレーティング,電圧制御 distribution system,streamlining distribution lines,storage battery,operation scheduling,dynamic rating,voltage regulation
要約(英語): Because of a large number of facilities in distribution lines, the rationalization of power distribution equipment is an important issue. In recent years, photovoltaic power generation system (PV) has become increasingly interconnected, so the use of distributed power sources and storage battery to streamline facilities is also being studied. However, large capacity of the storage battery is required to reduce power flow in distribution lines using only the storage battery. Dynamic rating (DR), on the other hand, dynamically changes the current capacity of transmission lines and transformers according to weather conditions and other factors. In this study, the necessary capacity of the storage battery is evaluated by distribution lines according to DR. Furthermore, considering transitional characteristics of the wire temperature about current that it takes several minutes to change after varying current can increase the allowable current capacity in distribution lines based on DR. Since downsizing distribution lines to rationalize distribution facilities increases the impedance in distribution system, there is a problem that the voltage fluctuation becomes large. Therefore, this paper proposes a method for calculating the necessary capacity of storage battery according to DR considering transient temperature change and voltage fluctuations in the distribution system. Then, the necessary capacity of the storage battery is evaluated through numerical simulations based on actual annual data.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.143 No.6 (2023) 特集:配電用変電所保護リレーシステムをはじめとした保護リレーシステム技術
本誌掲載ページ: 379-388 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/143/6/143_379/_article/-char/ja/
