事故電流の逆相分を用いた長距離配電線対応短絡保護システム

事故電流の逆相分を用いた長距離配電線対応短絡保護システム

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2023/06/01

タイトル(英語): A Short-Circuit Protection System Considering the Negative Sequence of Fault Current Available to Long Distribution Lines

著者名: 平山 晃己(名古屋工業大学大学院 工学研究科),青木 睦(名古屋工業大学大学院 工学研究科),天雨 徹(中部電力パワーグリッド(株)送変電部),大谷 哲夫((一財)電力中央研究所 グリッドイノベーション研究本部),小澤 辰哉(名菱電子(株)システム設計一課),對馬 宏介(名菱電子(株)システム設計一課)

著者名(英語): Koki Hirayama (Nagoya Institute of Technology), Mutsumi Aoki (Nagoya Institute of Technology), Toru Amau (Chubu Electric Power Grid Co. Inc.), Tetsuo Otani (Central Research Institute of Electric Power Industry), Tatsuya Ozawa (Meiryo Denshi), Kosuke Tsus

キーワード: 短絡保護,長距離配電線,二相短絡,逆相電流  short-circuit protection,long distribution line,two-phase short-circuit fault,negative-sequence current

要約(英語): A fault current measured at a distribution substation is small in case of a two-phase short-circuit fault near the end of a long distribution line. This characteristic makes it difficult to settle the overcurrent relay installed at the root of line because the load current could hardly be distinguished from the fault current. On the other hand, a negative-sequence current relay likely isolates such a two-phase short-circuit fault, but it may not operate properly due to effects of load on the distribution line. This study sets a proposal of short-circuit protection system considering the negative sequence of fault current that can be applied to long distribution lines. It also demonstrates how useful the proposed system is for isolating such a two-phase short-circuit fault on a long distribution line.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.143 No.6 (2023) 特集:配電用変電所保護リレーシステムをはじめとした保護リレーシステム技術

本誌掲載ページ: 389-395 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/143/6/143_389/_article/-char/ja/
