高周波レーザドップラ振動計による圧電ディスク型共振子の振動モードの観察

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2011/06/01

タイトル(英語): Vibration Mode Observation of Piezoelectric Disk-type Resonator by High Frequency Laser Doppler Vibrometer

著者名: 松村　武（情報通信研究機構 新世代ワイヤレス研究センター），江刺　正喜（東北大学原子分子材料科学高等研究機構），原田　博司（情報通信研究機構 新世代ワイヤレス研究センター），田中　秀治（東北大学大学院工学研究科ナノメカニクス専攻）

著者名(英語): Takeshi Matsumura (National Institute of Information and Communications Technology (NICT), New Generation Wireless Communications Research Center), Masayoshi Esashi (World Premier International Research Center, Advanced Institute for Materials Research), Hiroshi Harada (National Institute of Information and Communications Technology (NICT), New Generation Wireless Communications Research Center), Shuji Tanaka (Department of Nanomechanics, Tohoku University)

キーワード: マルチバンドフィルタ，ディスク型共振子，レーザドップラ振動測定，振動モード，有限要素法　　Mutli-band filter，Disk-type resonator，Laser Doppler vibrometry，Vibration mode，Finite element method (FEM)

要約(英語): For future mobile phones based on cognitive radio technology, a compact multi-band RF front-end architecture is strongly required and an integrated multi-band RF filter bank is a key component in it. Contour-mode resonators are receiving increased attention for a multi-band filter solution, because its resonant frequency is mainly determined by its size and shape, which are defined by lithography. However, spurious responses including flexural vibration are also excited due to its thin structure. To improve resonator performance and suppress spurious modes, visual observation with a laser probe system is very effective. In this paper, we have prototyped a mechanically-coupled disk-array filter, which consists of a Si disk and 2 disk-type resonators of higher-order wine-glass mode, and observed its vibration modes using a high-frequency laser-Doppler vibrometer (UHF-120, Polytec, Inc.). As a result, it was confirmed that higher order wine-glass mode vibration included a compound displacement, and that its out-of-plane vibration amplitude was much smaller than other flexural spurious modes. The observed vibration modes were compared with FEM (Finite Element Method) simulation results. In addition, it was also confirmed that the fabrication error, e.g. miss-alignment, induced asymmetric vibration.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.131 No.6 （2011） 特集：圧電材料・デバイス

本誌掲載ページ: 1086-1093 p

原稿種別: 論文／日本語
