LC移相器を用いた3方向ビーム切り替え給電回路

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2011/08/01

タイトル(英語): Feeding Circuit for Switching Beams in Three Directions Using LC Phase Shifter

著者名: 辻　正敏（香川高等専門学校　電気情報工学科）

著者名(英語): Masatoshi Tsuji (Department of Electrical & Computer Engineering, Kagawa National College of Technology)

キーワード: HTBM，移相器，フェイズドアレーアンテナ，給電回路　　HTBM，Phase shifter，Phased array antenna，feeding circuit

要約(英語): In order to obtain MMIC of a feed circuit called a HTBM (Hybrid Three Direction Beam Matrix) for making compact phased array antennas, the HTBM that uses LC circuitry as substitute for its transmission line was designed, experimentally fabricated and then evaluated at 1 MHz. In addition, a switch circuit for switching a beam direction was made using FETs and built into the HTBM. Antenna output was evaluated. Its results showed that the output gave close agreement with its simulation value and that the antenna-to-antenna phase difference and the level difference were less more than 7 degrees and 3.3 dB, respectively, in comparison with its ideal value.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.131 No.8 （2011）

本誌掲載ページ: 1512-1513 p

原稿種別: 研究開発レター／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/131/8/131_8_1512/_article/-char/ja/
