LCL形フィルタ付系統連系インバータの正弦波追従電流制御法

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2011/11/01

タイトル(英語): Sinusoidal Current-Tracking Control for Utility Interactive Inverter with an LCL Filter

著者名: 加藤　利次（同志社大学理工学部電気工学科），井上　馨（同志社大学理工学部電気工学科），堂ノ本　宜尚（同志社大学理工学部電気工学科）

著者名(英語): Toshiji Kato (Dept. of Electrical Engineering, Doshisha University), Kaoru Inoue (Dept. of Electrical Engineering, Doshisha University), Yoshihisa Donomoto (Dept. of Electrical Engineering, Doshisha University)

キーワード: 系統連系インバータ，正弦波補償器，状態フィードバック制御，定常偏差　　utility interactive inverter，sinusoidal compensator，state-feedback control，steady-state error

要約(英語): A voltage source inverter with an LCL filter is often used for a utility interface to control its output current to a grid side because of its harmonic reduction advantages. The integral compensator is often used to reduce the steady-state errors. However, there is always a control delay due to sinusoidal variations. This paper proposes a digital sinusoidal compensator which is based on the internal model principle to realize a fast sinusoidal response with no delay. It is based on the internal model principle to realize a response with no deviation for a periodic sinusoidal reference input. It has a simple numerator and a denominator z2 - 2z cosωT + 1 of a transfer function which is equal to the z function of a sinusoidal waveform of the angular frequency ω and the sample time T. Compensator and feedback gains of the inverter are determined by the dead-beat or the optimal control principle. The proposed method is investigated for performances and it is validated through simulation and experimental results by a DSP control system.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.131 No.11 （2011） 特集：電気関係学会関西連合大会

本誌掲載ページ: 1858-1863 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/131/11/131_11_1858/_article/-char/ja/
