位相シフト法における位相連結誤りの修復

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2011/12/01

タイトル(英語): Correcting Phase Unwrapping Errors with Phase Shifting Method

著者名: 加藤　嗣（名古屋工業大学大学院 情報工学専攻），田口　亮（名古屋工業大学大学院 情報工学専攻），保黒　政大（中部大学 工学部 電子情報工学科），梅崎　太造（名古屋工業大学大学院 情報工学専攻）

著者名(英語): Tsukasa Kato (Nagoya Institute of Technology), Ryo Taguchi (Nagoya Institute of Technology), Masahiro Hoguro (Chubu University), Taizo Umezaki (Nagoya Institute of Technology)

キーワード: 三次元計測，位相シフト法，位相連結問題　　three-dimensional measurement，phase shifting method，phase unwrapping problem

要約(英語): Phase Shifting Method, measuring method of three-dimensional shapes, is able to measure by high accuracy in short time. However there are some difficulties to acquire three-dimensional data because of phase unwrapping problem which occurs phase unwrapping errors and makes accuracy worse. Some of techniques have been used for avoiding the problem in the traditional methods. One of the traditional methods combines with space encoding method. This method could be robust and high accurate but requires several gray-code patterns other than phase shifting patterns. This makes measuring time longer. In this paper, we propose a correcting phase unwrapping error method which requires only phase shifting patterns to measure objects. The proposal method corrects over 99 [%] phase unwrapping errors. This result is almost same as the result of the traditional method. Therefore we are able to unwrap phase values as same accuracy as the traditional method by our proposal method despite reducing projecting patterns.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.131 No.12 （2011） 特集：電気関係学会東海支部連合大会

本誌掲載ページ: 2089-2096 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/131/12/131_12_2089/_article/-char/ja/
