CMOSインバータのみで構成する低電圧動作全差動OTAの設計と評価

CMOSインバータのみで構成する低電圧動作全差動OTAの設計と評価

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2013/02/01

タイトル(英語): Design and Evaluation of Fully Differential OTAs Based on CMOS Inverters

著者名: 矢澤 和樹(北見工業大学電気電子工学科),小森山 恵士(北見工業大学電気電子工学科),桑原 浩一(北見工業大学電気電子工学科),谷本 洋(北見工業大学電気電子工学科)

著者名(英語): Kazuki Yazawa (Kitami Institute of Technology), Keishi Komoriyama (Kitami Institute of Technology), Kouich Kuwahara (Kitami Institute of Technology), Hiroshi Tanimoto (Kitami Institute of Technology)

キーワード: CMOSインバータ,低電圧動作,全差動OTA,同相抑圧,高利得化  CMOS inverter,low-voltage operation,differential OTA,common-mode suppression,high voltage gain

要約(英語): There are strong demmands for low-voltage operating OPA/OTA in deep sub-micron CMOS processes. We have proposed a CMOS inverter based two-stage OTA configuration named F/F+F/B OTA, which can operate 1V to 1.8V of supply voltage, for an 0.18μm CMOS process. In this report, three series of fabrication results for the proposed F/F+F/B OTA configurations are presented with their design details. We have improved common-mode rejection ratio and voltage gain over the prototype chip. The revised chip demonstrated 79dB of differential voltage gain, unity frequency of 3.8MHz, with 124dB of CMRR, from 1.0V of power supply with 200μA of current consumption.

本誌: 電気学会論文誌C(電子・情報・システム部門誌) Vol.133 No.2 (2013) 特集:省電力時代の電子回路技術

本誌掲載ページ: 251-259 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/133/2/133_251/_article/-char/ja/
