Feature-based Alignment Method for Projecting Virtual Content on a Movable Paper Map

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2013/03/01

タイトル(英語): Feature-based Alignment Method for Projecting Virtual Content on a Movable Paper Map

著者名: Sandy Martedi (Keio University), Maki Sugimoto (Keio University), Hideo Saito (Keio University), Bruce Thomas (University of South Australia)

著者名(英語): Sandy Martedi (Keio University), Maki Sugimoto (Keio University), Hideo Saito (Keio University), Bruce Thomas (University of South Australia)

キーワード: spatial augmented reality，random dot marker method，geographical information system

要約(英語): In this paper we propose a feature-based alignment method for visualizing geographical content on a movable paper map using non-calibrated projector-camera pair. In order to project correctly aligned geographical content on a movable paper map, we detect two kinds of features: printed features and projected features on a paper map. First, we print landmark points as map features on the paper map for registration purpose. We then project landmark points onto the paper map. We then detect these printed and projected features simultaneously. The transformation from the projector coordinate system to the image coordinate system is estimated using the feature correspondences. This transformation is used to warp the geographical content before the corrected projection. In succeeding frames, the features are tracked in order to update the transformation. We evaluated our method against the motion of the paper map, the camera and the projector with average projection error of 9.5 pixels.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.133 No.3 （2013） 特集Ⅰ：電磁波の技術と科学および信号処理　特集Ⅱ：電子・情報・システム分野の最先端技術

本誌掲載ページ: 672-679 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/133/3/133_672/_article/-char/ja/
