帯電した人体からのESDにおける絶縁破壊電界の帯電電圧依存性

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2013/12/02

タイトル(英語): Dependence of Gap Breakdown Field on Charge Voltage in ESD caused by Charged Human-body

著者名: 高　義礼（釧路工業高等専門学校 電子工学科），加川　義久（名古屋工業大学大学院），藤原　修（名古屋工業大学大学院）

著者名(英語): Yoshinori Taka (Department of Electronic Engineering, Kushiro National College of Technology), Yoshihisa Kagawa (Graduate School of Engineering, Nagoya Institute of Technology), Osamu Fujiwara (Graduate School of Engineering, Nagoya Institute of Technology)

キーワード: 帯電人体，静電気放電，絶縁破壊電界，帯電電圧依存性　　charged human-body，electrostatic discharge，breakdown field，dependence on charge voltage

要約(英語): We previously measured discharge currents due to collision of the hand-held metal piece of a charged human through a 50 Ω SMA connector with a 6 GHz or 12 GHz digital oscilloscope, and then proposed an equivalent circuit model to calculate the discharge current. This model enables one to derive a discharge voltage across the spark gap from the measured discharge current, which revealed that at charge voltages bellow 600 V the estimated breakdown fields from the discharge voltages are almost kept constant (2-3×107 [V/m]) regardless of the different approach speeds of the metal piece. In this study, with a 12 GHz wide-band digital oscilloscope, we measured the discharge currents through a commercially available IEC calibration current target in order to estimate breakdown fields at different charge voltages from 200 V to 8,000 V. As a result, we confirmed that at charge voltages below 400 V, the breakdown fields show an almost constant value of (2-3)×107 V/m. It was also found that the breakdown fields at charge voltages from 600 V to 1,000 V decrease with charge voltages, and approximately agree with the Pachen's law, while at 2,000 V to 8,000 V they are smaller compared to the results calculated from the Pachen's law.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.133 No.12 （2013） 特集：電気関係学会東海支部連合大会

本誌掲載ページ: 2149-2154 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/133/12/133_2149/_article/-char/ja/
