A 60 GHz CMOS Rectifier with -27.5 dBm Sensitivity for mm-Wave Power Detection and Its Application

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2014/01/01

タイトル(英語): A 60 GHz CMOS Rectifier with -27.5 dBm Sensitivity for mm-Wave Power Detection and Its Application

著者名: Shusuke Kawai (Wireless System Laboratory, Corporate Research and Development Center, Toshiba Corporation), Toshiya Mitomo (Wireless System Laboratory, Corporate Research and Development Center, Toshiba Corporation), Shigehito Saigusa (Wireless System Lab

著者名(英語): Shusuke Kawai (Wireless System Laboratory, Corporate Research and Development Center, Toshiba Corporation), Toshiya Mitomo (Wireless System Laboratory, Corporate Research and Development Center, Toshiba Corporation), Shigehito Saigusa (Wireless System Laboratory, Corporate Research and Development Center, Toshiba Corporation)

キーワード: rectifier，WuRX，millimeter-wave，shielded capacitor

要約(英語): A CMOS rectifier that converts 60 GHz signal to DC voltage is presented for millimeter-Wave (mm-Wave) power detection. The sensitivity of the rectifier is -27.5 dBm, which is the highest sensitivity compared with previous works. The optimization method for the rectifier is proposed considering the power matching design and loss of the passive devices at 60 GHz. According to the proposed method, the number of stage should be decreased because the stacked structure that is often used at frequency of several GHz doesn't increase the sensitivity in the case of 60 GHz. The loss of the passive devices is minimized by adopting the proposed optimization method. Additionally, the 60 GHz Wake up Receiver (WuRX) is discussed as application of the rectifier proposed in this work.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.134 No.1 （2014） 特集：スマート社会を支える電子回路技術

本誌掲載ページ: 2023/02/07 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/134/1/134_2/_article/-char/ja/
