位相シフトデジタルホログラフィによる三次元計測システムの開発

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2014/01/01

タイトル(英語): Development of 3D Measurement System using Phase Shift Digital Holography

著者名: Qiyue Yu（名古屋工業大学大学院 情報工学専攻），田口　亮（名古屋工業大学大学院 情報工学専攻），保黒　政大（中部大学 工学部 電子情報工学科），堀米　秀嘉（（有）ホーリーマイン），梅崎　太造（名古屋工業大学大学院 情報工学専攻）

著者名(英語): Qiyue Yu (Graduate School of Engineering, Department of Computer Science and Engineering, Nagoya Institute of Technology), Ryo Taguchi (Graduate School of Engineering, Department of Computer Science and Engineering, Nagoya Institute of Technology), Masahiro Hoguro (College of Engineering, Department of Electronics and Information Engineering, Chubu University), Hideyoshi Horimai (HolyMine Corporation), Taizou Umezaki (Graduate School of Engineering, Department of Computer Science and Engineering, Nagoya Institute of Technology)

キーワード: 三次元計測，位相シフトデジタルホログラフィ，光学システム　　three-dimensional measurement，phase shift digital holography，optical system

要約(英語): In these years, demand for three-dimensional measurement technology is higher. However, in many of the traditional three-dimensional measurement methods, such as the method using phase shift patterns projection, it is difficult to measure shape of specular reflective and transparent objects, because power of reflected light is too high from specular reflective objects or too low from transparent objects, so that information of reflected light cannot be acquired accurately by digital camera. Digital holography has been used for resolving this problem. In traditional digital holography, interference fringe of measure object's light wave and reference light wave is recorded by digital camera. Using Fresnel diffraction principle, phase information of measure object's light wave can be required and shape of measure object can be calculated using interferometry principle. It can be used for reflective and transparent objects measurement, but as the principle of Fresnel diffraction, DC and conjugate components exist in calculated phase information as noises, so accuracy of measurement is lower. Phase shift digital holography is able to remove noises using special devices to change phase of reference light wave, but the devices are high price and the system is complex, so practical application of phase shift digital holography is difficult. In this paper, we propose a new method of phase shift digital holography using light detection principle. Simultaneously, we propose a digital holography reconstruction method using the convolution approach rather than the traditional Fresnel approach. The proposal method realized a compact phase shifting holography system with low price and a high accuracy three-dimensional measurement method. Therefore, we are able to realize the practical applications of digital holography with low price and higher accuracy.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.134 No.1 （2014） 特集：スマート社会を支える電子回路技術

本誌掲載ページ: 56-62 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/134/1/134_56/_article/-char/ja/
