ミスマッチ誤差に関する受動複素フィルタの素子感度についての予備検討

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2015/07/01

タイトル(英語): A Preliminary Study on Sensitivity of Passive Complex Filters to Mismatch Errors

著者名: 武藤　浩二（長崎大学教育学部）

著者名(英語): Cosy Muto (Faculty of Education, Nagasaki University)

キーワード: 受動複素フィルタ，素子感度，虚数抵抗，ミスマッチ誤差，蓄積エネルギー　　passive complex filter，sensitivity，imaginary resistor，mismatch error，stored energy

要約(英語): It is well known that doubly terminated LC filters are low sensitive to element value deviation in the passband. This property has been expanded to passive complex filters, however, only the case for tracking deviation between real and imaginary part elements has proved. Although numerical calculation methods for arbitrary deviations have proposed, there is no mathematical analysis on mismatch error. In this paper, a preliminary study for passive complex filter sensitivity to mismatch errors between real and imaginary pair elements is given. At first, we show that any mismatch error can be decomposed into tracking and differential errors and that the latter is the subject to be analyzed. Then, we consider a passive complex filter as a multi-port output real filter and analyze its sensitivity in passband.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.135 No.7 （2015） 特集：平成26 年電子・情報・システム部門大会

本誌掲載ページ: 739-743 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/135/7/135_739/_article/-char/ja/
