磁気結合を利用した高電力密度昇圧コンバータにおける小型化性能の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2015/07/01

タイトル(英語): An Investigation of Size-reduction Effects in High Power Density Boost Converters with a Magnetic Coupling

著者名: 青砥　匠吾（島根大学総合理工学研究科総合理工学専攻），木村　翔太（島根大学総合理工学研究科総合理工学専攻），今岡　淳（島根大学総合理工学研究科総合理工学専攻），山本　真義（島根大学総合理工学研究科総合理工学専攻）

著者名(英語): Shogo Aoto (Department of Science and Engineering, Graduate School of Science and Engineering, Shimane University), Shota Kimura (Department of Science and Engineering, Graduate School of Science and Engineering, Shimane University), Jun Imaoka (Department of Science and Engineering, Graduate School of Science and Engineering, Shimane University), Masayoshi Yamamoto (Department of Science and Engineering, Graduate School of Science and Engineering, Shimane University)

キーワード: 統合磁気部品，高電力密度化，密結合インダクタ，疎結合インダクタ　　integrated magnetic components，high power density，close-coupled indictors (CCI)，loose-coupled inductors (LCI)

要約(英語): The DC-DC converter using integrated magnetic components that may achieve high power density has gained attention in environmentally-friendly cars such as electric vehicles (EVs) and hybrid electric vehicles (HEVs). This paper focused on interleaved boost converters using close-coupled inductors and loose-coupled inductors that are the integrated magnetic components. Following, detailed electromagnetically analysis for these circuit types were conducted in order to calculate volume of inductors and capacitors that are occupied the large part of space in the converters. The total volume of inductors and capacitors in these circuits were demonstrated clearly through comparison with conventional circuits such as an interleaved boost converter and a single-phase boost converter. As a result, it became clear that interleaved boost converter using loose-coupled inductors was effective for miniaturization of total volume. Further, duty ratio of the minimum volume of close-coupled inductors method is different from the duty ratio of the minimum volume of loose-coupled inductor method.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.135 No.7 （2015） 特集：平成26 年電子・情報・システム部門大会

本誌掲載ページ: 776-784 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/135/7/135_776/_article/-char/ja/
