集中定数素子を用いた小型ラットレース回路の製作と評価

集中定数素子を用いた小型ラットレース回路の製作と評価

通常価格 ¥550 JPY
通常価格 セール価格 ¥550 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2015/08/01

タイトル(英語): Fabrication and Evaluation of a Compact Rat-Race Circuit Using Lumped Parameter Elements

著者名: 内海 智博(香川高等専門学校),辻 正敏(香川高等専門学校)

著者名(英語): Tomohiro Utsumi (Kagawa National College of Technology), Masatoshi Tsuji (Kagawa National College of Technology)

キーワード: ラットレース回路,ハイブリッドリング,移相器  Rat-race circuit,Hybrid ring,Phase Shifter

要約(英語): This paper proposes a compact rat-race circuit using LC lumped parameter elements. The circuit, which converted transmission lines into pi-type phase shifters, consists of six lumped parameter elements. Therefore, the circuit can be the size of 1/267, while having a conventional performance. The prototype for use in 1GHz band is fabricated on a substrate, and the propagation characteristics and reflection characteristics of each port are measured. The measurement results agreed well with those of the simulation. The dimensions of the circuit are approximately 5.5mm×5.5mm.

本誌: 電気学会論文誌C(電子・情報・システム部門誌) Vol.135 No.8 (2015) 特集:知能メカトロニクス分野と連携する知覚情報技術

本誌掲載ページ: 1030-1031 p

原稿種別: 研究開発レター/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/135/8/135_1030/_article/-char/ja/
