擬似アナログ信号を用いたスペクトラム拡散によるスイッチング電源回路のEMI低減手法の提案

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2016/01/01

タイトル(英語): EMI Reduction Technique for Switching Converter by Spectrum Spread using Pseudo Analog Signal

著者名: 高井　伸和（群馬大学　大学院理工学府　電子情報部門），金谷　浩太郎（群馬大学　理工学府　電子情報・数理教育プログラム），小堀　康功（小山工業高等専門学校　電気電子創造工学科），小林　春夫（群馬大学　大学院理工学府　電子情報部門）

著者名(英語): Nobukazu Takai (Devition of Electronics and Inormation, Graduate School of Science and Technology, Gunma University), Kotaro Kaneya (Education Program of Electronics and Informatics, Graduate School of Science and Technology, Gunma University), Yasunori Kobori (National Institute of Technology, Oyama College. Dep. of Innovative Electrical and Electronic Engineering), Haruo Kobayashi (Devition of Electronics and Inormation, Graduate School of Science and Technology, Gunma University)

キーワード: 擬似アナログ信号，擬似ランダム信号，電圧制御発振器，位相同期回路，スイッチング電源　　pseudo analog signal，pseudo random signal，voltage controlled oscillator，phase locked loop，switching converter

要約(英語): In this paper, EMI reduction method for switching power supply circuit by using PLL circuit as reference signal whose spectrum is spreaded, is proposed. M-sequence pseudo random signal is employed for PLL spectrum spread. Next, we extend this low bit M-sequence pseudo random signal to spectrum spread signal called “pseudo analog signal. ” The proposed pseudo analog signal can realize that the effect of the spectrum spread is wide even if the number of bit of the pseudo random circuit is small. Simulations and measurement are performed to verify the validity of the proposed method. Simulation and measurement results indicate that the proposed method have a large effect of the spectrum spread.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.136 No.1 （2016） 特集：電子回路関連技術

本誌掲載ページ: 43-49 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/136/1/136_43/_article/-char/ja/
