Talbot効果による傾斜角度格子投影手法とリニアファイバアレイを用いた位相シフトによる3次元計測

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2016/08/01

タイトル(英語): 3D Shape Measurement Using Inclined Small Pitch Fringe Projection Method with Talbot Effect and Phase Shifting Method with Linear Fiber arrays

著者名: 林　拓実（和歌山大学大学院システム工学研究科），村田　頼信（和歌山大学システム工学部），藤垣　元治（福井大学大学院工学研究科）

著者名(英語): Takumi Hayashi (Graduate School of Systems Engineering, Wakayama University), Yorinobu Murata (Faculty of Systems Engineering, Wakayama University), Motoharu Fujigaki (Graduate School of Engineering, University of Fukui)

キーワード: 格子投影法，3次元計測，微細格子投影，Talbot効果，リニアファイバアレイ　　Fringe projection method，3D shape measurement，Small pitch fringe projection，Talbot effect，Linear fiber array

要約(英語): 3D shape measurement systems that use contactless methods are required for quality inspection of metal molds and electronic parts in industrial fields. A fringe projection method with phase-shifting method offers the advantages of high precision and high speed. Recently, since the size of electronic parts has become smaller, the pitch of a grating pattern projected onto a specimen should also become smaller. In this paper, a small pitch fringe projection method using Talbot effect with an SLD (Super luminescent diode) and a method to incline the appearing area of the fringe pattern are proposed. A linear fiber array with four cores is prototyped. A phase-shifting method using the linear fiber array is also proposed. The effectiveness is confirmed with the experimental results of shape measurement using a 3D shape measurement setup built with proposed method.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.136 No.8 （2016） 特集Ⅰ：知能メカトロニクス分野と連携する知覚情報技術　特集Ⅱ：国際会議ICESS 2015

本誌掲載ページ: 1063-1070 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/136/8/136_1063/_article/-char/ja/
