RC両終端形RCポリフェーズフィルタの構成とその応用

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2017/02/01

タイトル(英語): Synthesis of a Doubly RC Terminated RC Polyphaser Filter and Its Application

著者名: 島田　泰奨（筑波大学 システム情報工学研究科），庄野　和宏（筑波大学 システム情報工学研究科）

著者名(英語): Taisuke Shimada (Graduate School of Systems and Information Engineering, University of Tsukuba), Kazuhiro Shouno (Graduate School of Systems and Information Engineering, University of Tsukuba)

キーワード: 複素，フィルタ，RCポリフェーズフィルタ，両側終端，アナログ，受動　　complex，filter，RC polyphase filter，doubly terminated，analog，passive

要約(英語): In this paper, a synthesis of a doubly RC terminated RC polyphase filter is proposed. The terminating circuits on both sides are composed of resistors and capacitors connected in parallel. Especially, in many cases, the terminating circuit at the load side becomes an equivalent circuit of the following building blocks such as MOS amplifiers. It is described that the transfer response of the proposed circuit becomes the same as that of the conational one. The proposed circuit is obtained through the coefficient matching method in the same as the conventional polyphase filter. In addition, the RC-parallel circuit at the source side is approximately modified to the RC-series one in order to take the source resistance included in the voltage source into account. As an example, a third-order doubly RC terminated RC polyphase filter and its approximately modified one are designed. The validity of the proposed method is confirmed through computer simulation and experiment.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.137 No.2 （2017） 大特集：電子・情報・システム部門誌 30周年記念「電子・情報・システム技術によるイノベーション」

本誌掲載ページ: 229-235 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/137/2/137_229/_article/-char/ja/
