タップインダクタ方式-高昇圧比DC-DCコンバータの昇圧比と電力効率の解析の精度向上に関する研究

タップインダクタ方式-高昇圧比DC-DCコンバータの昇圧比と電力効率の解析の精度向上に関する研究

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2017/05/01

タイトル(英語): Study on Improving Precision of Analysis of Boost Ratio and Power Efficiency of Tapped-Inductor DC-DC Converter Circuit

著者名: 劉 雨瀚(東洋大学大学院 理工学研究科 電気電子情報専攻),関口 諒(東洋大学大学院 理工学研究科 電気電子情報専攻),佐野 勇司(東洋大学大学院 理工学研究科 電気電子情報専攻)

著者名(英語): Yuhan Liu (Graduate School of Science and Engineering, Course of Electricity, Electronics and Communications, Toyo University), Ryo Sekiguchi (Graduate School of Science and Engineering, Course of Electricity, Electronics and Communications, Toyo University), Yuji Sano (Graduate School of Science and Engineering, Course of Electricity, Electronics and Communications, Toyo University)

キーワード: スイッチング電源,DC-DCコンバータ,昇圧回路,昇圧比,電力効率,解析  Switched-mode power supply,DC-DC converter,Boost circuit,Boost ratio,Power efficiency,Analysis

要約(英語): Analysis precision of boost ratio and power efficiency in boost DC-DC converter circuit is improved by proposing adaptive equivalent circuit of output diode of the circuit. In experiment, boost ratio and power efficiency in high boost ratio circuit were 9.89 and 76.5 percent respectively with its load resistance of 20Ω driven by output voltage 10V. In experimental results, error in theoretical values of boost ratio compared with the measured values of that was reduced to -3.79% from 57.5% in the conventional circuit. In a tapped-inductor high boost ratio circuit, error in theoretical values of boost ratio was reduced to 3.54% from 31.8%. Error in theoretical values of power efficiency with the measured values of that was reduced to 5.51% from 33.2% in the conventional circuit. In a high boost ratio circuit, error in theoretical values of power efficiency was reduced to -3.32% from 17.3%. Power loss of every element in boost DC-DC converter circuits was analyzed with high precision by analysis of inductance current waveforms in those circuits. Error in theoretical values of power loss compared with measured values was reduced to equal or less than 5%.

本誌: 電気学会論文誌C(電子・情報・システム部門誌) Vol.137 No.5 (2017)

本誌掲載ページ: 687-700 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/137/5/137_687/_article/-char/ja/
