A Proposal for Downconverting A-to-D Converter Based on Even-Harmonic Mixer and ΔΣ-TDC

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2018/01/01

タイトル(英語): A Proposal for Downconverting A-to-D Converter Based on Even-Harmonic Mixer and ΔΣ-TDC

著者名: Takuto Takahashi (Department of Electrical and Electronic Engineering, Kitami Institute of Technology), Toshiki Sugimoto (Department of Electrical and Electronic Engineering, Kitami Institute of Technology), Hiroshi Tanimoto (Department of Electrical and

著者名(英語): Takuto Takahashi (Department of Electrical and Electronic Engineering, Kitami Institute of Technology), Toshiki Sugimoto (Department of Electrical and Electronic Engineering, Kitami Institute of Technology), Hiroshi Tanimoto (Department of Electrical and

キーワード: even-harmonic mixer，delta-sigma-TDC，A-to-D Converter，downconverter，direct conversion，Time-to-Digital Converter

要約(英語): A novel architecture of downconverting A-to-D Converter is proposed, which is based on even-harmonic mixer and ΔΣ Time-to-Digital Converter. Analog circuits are minimized by the proposed architecture. As a design study, a test chip of 200 MHz RF signal to baseband downconverter is designed and fabricated. The design uses a standard 0.18 μm CMOS technology, and the simulation results verify the operation of the proposed architecture. Measurement result is presented and it verified the functionality of the fabricated test chip.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.138 No.1 （2018） 特集：電子回路関連技術

本誌掲載ページ: 50-56 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/138/1/138_50/_article/-char/ja/
