Design of H-Plane Waveguide Mode Converter for Microwave Fryer

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2018/02/01

タイトル(英語): Design of H-Plane Waveguide Mode Converter for Microwave Fryer

著者名: Shuhei Takaoka (Graduate School of Engineering, University of Hyogo), Taro Inada (Graduate School of Engineering, University of Hyogo), Tadashi Kawai (Graduate School of Engineering, University of Hyogo), Akira Enokihara (Graduate School of Engineering, U

著者名(英語): Shuhei Takaoka (Graduate School of Engineering, University of Hyogo), Taro Inada (Graduate School of Engineering, University of Hyogo), Tadashi Kawai (Graduate School of Engineering, University of Hyogo), Akira Enokihara (Graduate School of Engineering, U

キーワード: microwave heating，microwave fryer，waveguide mode converter，H-plane planar circuit approach

要約(英語): This paper describes an H-plane rectangular waveguide TE10-TEn0 mode converter for microwave fryers using microwave dielectric heating. The mode converter consists of a standard rectangular waveguide and a multiple mode one for TEn0 mode microwave. The multiple mode waveguide has several metallic posts in order to match of the input port and suppress unnecessary modes. As a result of optimizing the circuit configuration of the converter based on the H-plane planar circuit approach at a center frequency of 2.45GHz, practical characteristics for microwave fryers can be realized. The validity of this design procedure is confirmed by a commercial electromagnetic simulator (ANSYS HFSS). From experimental result of oil heating by means of twelve heating units, it was possible to confirm the temperature rise up to 180 degrees and the effectiveness of this proposed Microwave fryer.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.138 No.2 （2018） 特集：電磁波応用を加速するための高周波回路・計測・システム技術

本誌掲載ページ: 124-128 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/138/2/138_124/_article/-char/ja/
