5レベルインバータの直流リンク入力電圧のバランス化のためのダブルマッピング方式による空間ベクトル変調法

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2018/11/01

タイトル(英語): Double-Mapping-Based SVM Method for Balancing DC-Link Input Voltages of a Five-Level Inverter

著者名: 加藤　利次（同志社大学理工学部電気工学科），井上　馨（同志社大学理工学部電気工学科），園　拓実（同志社大学理工学部電気工学科），冨永　要（同志社大学理工学部電気工学科）

著者名(英語): Toshiji Kato (Department of Electrical Engineering, Doshisha University), Kaoru Inoue (Department of Electrical Engineering, Doshisha University), Takumi Sono (Department of Electrical Engineering, Doshisha University), Kaname Tominaga (Department of Elec

キーワード: 5レベルインバータ，直流リンク入力電圧，空間ベクトル変調，ダブルマッピング法，NPCインバータ，ディジタル制御　　Five-Level Inverter，DC-Link Input Voltage，Space Vector Modulation，Double Mapping Method，NPC Inverter，Digital Control

要約(英語): A multi-level inverter has potential advantages in high blocking voltages and reduced harmonics. However, it has a technically challenging subject that the DC input voltages must be balanced. This paper proposes and investigates a new double-mapping-based space-vector modulation (SVM) method to solve the subject without any additional circuit. The proposed method consists of two steps. One is the SV map data generation for the five-level NPC inverter based on a general principle to utilize redundant SVs. The other is the optimal selection of the SV pattern which balances the the DC input voltages based on the double-mapping-based SVM method which has two different kind of control schemes for low and high modulation indexes. The proposed method is investigated and validated through simulated results by a digital control system.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.138 No.11 （2018） 特集：電気関係学会関西連合大会

本誌掲載ページ: 1319-1326 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/138/11/138_1319/_article/-char/ja/
