帰還係数可変化によるΔΣ型A/D変換器の広ダイナミックレンジ化
帰還係数可変化によるΔΣ型A/D変換器の広ダイナミックレンジ化
カテゴリ: 論文誌(論文単位)
グループ名: 【C】電子・情報・システム部門
発行日: 2021/01/01
タイトル(英語): A Expanding Technique of Dynamic Range for Delta-Sigma ADC by Variable Feedback Coefficient
著者名: 藤田 隆佑(青山学院大学大学理工学研究科電気電子工学コース),稲垣 雄志(青山学院大学大学理工学部電気電子工学科),松谷 康之(青山学院大学大学理工学部電気電子工学科)
著者名(英語): Ryusuke Fujita (Electrical Engineering and Electronics Course, Graduate School of Science and Engineering, Aoyama Gakuin University), Yuji Inagaki (College of Science and Engineering, Aoyama Gakuin University), Yasuyuki Matsuya (College of Science and Eng
キーワード: ΔΣ型ADC,可変帰還係数,広入力ダイナミックレンジ delta-sigma ADC,variable feedback coefficient,wide input dynamic range
要約(英語): In this paper, we propose the expanding technique of the ΔΣ ADC dynamic range by changing a feedback coefficient. The feedback coefficient is switched from 1 to 0.5 according to the input signal voltage value. It can improve the SNR at the small amplitude input reducing the quantization noise by the small feedback coefficient. We confirmed by the circuit simulation that the proposed circuit archives a dynamic range of 102 dB, and improves SNR of 6 dB from the conventional circuit.
本誌: 電気学会論文誌C(電子・情報・システム部門誌) Vol.141 No.1 (2021) 特集:電子回路関連技術
本誌掲載ページ: 18-24 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/141/1/141_18/_article/-char/ja/
