大電流発生装置に搭載されるトランスの電力損失を低減する駆動方式に関する研究
大電流発生装置に搭載されるトランスの電力損失を低減する駆動方式に関する研究
カテゴリ: 論文誌(論文単位)
グループ名: 【C】電子・情報・システム部門
発行日: 2021/01/01
タイトル(英語): Study on Driving Method to Reduce Power Loss of Transformer Mounted on Large Current Generator
著者名: 徐 逢員(東洋大学大学院 理工学研究科 電気電子情報専攻),佐野 勇司(東洋大学大学院 理工学研究科 電気電子情報専攻)
著者名(英語): Houin Jo (Graduate School of Science and Engineering, Course of Electricity, Electronics and Communications, Toyo University), Yuji Sano (Graduate School of Science and Engineering, Course of Electricity, Electronics and Communications, Toyo University)
キーワード: 大電流発生装置,トランス,電力損失,ヒステリシス損,B-Hカーブ,ユニポーラPWM large current generator,transformer,power loss,hysteresis loss,B-H curve,unipolar PWM
要約(英語): A large current generating apparatus is used for a power system testing apparatus or a power supply apparatus for a magnetic inspection apparatus, and supplies a large current output to a low resistance load. The transformer used for large current output is driven at commercial frequency and the challenge is to improve power efficiency.In this paper, by changing the wave-form of driving voltage for the transformer used in the high power output equipment to the ternary pulse of the same frequency from the conventional sine wave, it was shown that the iron loss of transformer could be reduced applying by 14% while maintaining the effective value of the output current. In addition, it was also shown that by the unipolar PWM driving for the transformer, the iron loss could be reduced to 89% of that in bipolar PWM system with the miniaturization of the transformer size.
本誌: 電気学会論文誌C(電子・情報・システム部門誌) Vol.141 No.1 (2021) 特集:電子回路関連技術
本誌掲載ページ: 50-58 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/141/1/141_50/_article/-char/ja/
