断熱的論理回路を用いた12段階調光回路の小面積および低消費電力設計

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2021/12/01

タイトル(英語): Design of Small-area and Low-power Expanded-PWM Using Adiabatic Dynamic CMOS Logic for 12-step Dimming Control Circuit

著者名: 吉田　圭佑（山形大学大学院 理工学研究科），趙　勝一（山形大学大学院 理工学研究科），横山　道央（山形大学大学院 理工学研究科）

著者名(英語): Keisuke Yoshida (Graduate School of Science and Engineering, Yamagata University), Seung-Il Cho (Graduate School of Science and Engineering, Yamagata University), Michio Yokoyama (Graduate School of Science and Engineering, Yamagata University)

キーワード: 低消費電力設計，断熱的論理回路，PWM回路，D-FF回路，多段階調光，マルチプレクサ　　low-power design，adiabatic logic，PWM circuits，D-FF circuits，multi-step dimming，multiplexer

要約(英語): In this paper, we propose design of low-power digital expanded-pulse width modulation (E-PWM) using adiabatic dynamic CMOS logic (ADCL) for 12-step dimming control circuit of an LED lighting system. As results of HSPICE simulation, power consumption of E-PWM was reduced by approximately 90% compared to conventional CMOS 12-step dimming PWM circuits. Furthermore, the layout of E-PWM was designed using 0.18μm standard CMOS process and circuit area of 12-step dimming PWM circuit was compared between previous studies and this study. The area of the design layout is not only significantly reduced compared to the dimming PWM of previous studies using ADCL, but also reduced approximately 68% compared to the conventional CMOS 12-step dimming PWM circuit.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.141 No.12 （2021） 特集Ⅰ：電気・電子・情報関係学会東海支部連合大会　特集Ⅱ：研究会優秀論文

本誌掲載ページ: 1286-1295 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/141/12/141_1286/_article/-char/ja/
