機械設計における3D CADを中心とした1DCAE Virtual Engineering環境の構築

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2023/03/01

タイトル(英語): Construction of 1DCAE Virtual Engineering System Centered on the 3D CAD for Mechanical Design

著者名: 工藤　卓史（（株）日立インダストリアルプロダクツ），中尾　雄次（日立三菱水力（株）），小林　俊一（信州大学学術研究院（繊維学系））

著者名(英語): Takashi Kudoh (Hitachi Industrial Products, Ltd), Yuji Nakao (Hitachi Mitsubishi Hydro Corporation), Shunichi Kobayashi (Shinshu University)

キーワード: バーチャルエンジニアリング，1DCAE，設計仕様，水車_x000D_　　virtual engineering，1DCAE，design parameter，water turbine

要約(英語): It is proposed to incorporate 1DCAE into a virtual engineering system in mechanical system design. In order to continue using an established virtual engineering system for a long time, it is necessary to modify it in line with the evolution of CAD, CAE, analysis, and evaluation technologies. If information in CAD or the like is coded directly in the system, it will be necessary to make changes to the system. Meanwhile, if the evaluation method, etc. is changed, the user interface of the system may need to be changed. These changes require software engineers and are costly and time-consuming.In this paper, we propose that the elements in the system be independent, that the relationship between each element be defined by JSM, and that 3D-CAD be used for user interfaces. This will allow even those without software language skills to update the technology and create a long-lasting virtual engineering environment.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.143 No.3 （2023） 特集：スマートシステムと計測・制御技術　－SDGsへの貢献－

本誌掲載ページ: 364-371 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/143/3/143_364/_article/-char/ja/
