小中学生を対象としたアナログLSI設計講座

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2023/10/02

タイトル(英語): Analog LSI Design Education for Elementary and Junior High School Students

著者名: 清水　暁生（有明工業高等専門学校 創造工学科），吉冨　貴司（八女工業高等学校電気科），野口　卓朗（有明工業高等専門学校 創造工学科），石川　洋平（有明工業高等専門学校 創造工学科），深井　澄夫（佐賀大学理工学部）

著者名(英語): Akio Shimizu (Department of Creative Engineering, National Institute of Technology, Ariake College), Takashi Yoshitomi (Department of Electrical Engineering, Yame Technical High School), Takuro Noguchi (Department of Creative Engineering, National Institute of Technology, Ariake College), Yohei Ishikawa (Department of Creative Engineering, National Institute of Technology, Ariake College), Sumio Fukai (Faculty of Science and Engineering, Saga University)

キーワード: 電子回路教育，アナログLSI，オペアンプ　　electronic circuit education，analog LSI，operational amplifier

要約(英語): In this paper, an education system for elementary and junior high school students to design analog LSI is proposed, and an analog LSI design course conducted using the education system is reported. In the proposed course, a CMOS OP-amp is designed by connecting prepared circuit blocks. The designed CMOS OP-amp is fabricated by phenitec 0.6 μm CMOS process, and connected to an external circuit for using as an audio amplifier. The students will understand the characteristics of the circuit based on the difference in sound. The students can design, simulate and layout CMOS operational amplifier in three hours, and evaluate the circuit in 30 minutes.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.143 No.10 （2023）

本誌掲載ページ: 995-1002 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/143/10/143_995/_article/-char/ja/
