ペルチェ素子の熱電エネルギー変換の解析と汎用モノリシックIC化

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2024/04/01

タイトル(英語): Analysis of Thermoelectric Energy Conversion in Peltier Devices and Making the Devices into General-Purpose Monolithic IC Structure

著者名: 佐藤　龍太郎（東洋大学大学院 理工学研究科 電気電子情報専攻），佐野　勇司（東洋大学大学院 理工学研究科 電気電子情報専攻）

著者名(英語): Ryutaro Sato (Graduate School of Science and Engineering, Course of Electricity, Electronics and Communications, Toyo University), Yuji Sano (Graduate School of Science and Engineering, Cource of Electricity, Electronics and Communications, Toyo University)

キーワード: ペルチェ素子，熱等価回路，モノリシックIC，CMOSプロセス，長寿命化　　peltier device，thermal equivalent circuit，monolithic integrated circuit，CMOS process，long life

要約(英語): Peltier device is used for both thermoelectric cooling and thermoelectric power generation, where the Peltier and Seebeck effect occur simultaneously when current is applied. Conventional thermal equivalent circuits for Peltier device consider only the effects that are used out of the effects that occur simultaneously. Therefore, in the past, our laboratory proposed a thermal equivalent circuit considers the Seebeck effect in thermoelectric cooling. In this paper, we propose a thermal equivalent circuit that considers the Peltier effect in thermoelectric generation. Furthermore, from the analysis results of the thermal and electrical equivalent circuits during thermoelectric cooling and thermoelectric power generation, the amount of thermal and electrical energy converted is quantitatively clarified.Also, General-purpose Peltier devices have a hybrid integrated circuit structure in which heat is transferred through a semiconductor and a welded metal, and the difference in thermal expansion coefficient between the two causes a short life. Therefore, the authors devised a structure in which the Peltier device is completely monolithic and fabricated a prototype Peltier integrated circuit using a general-purpose CMOS process to extend the life of Peltier device. we report on the structure of the prototype monolithic Peltier IC and the experimental confirmation of the thermoelectric effect.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.144 No.4 （2024） 特集Ⅰ：量子・情報・エレクトロニクスの医療/ヘルスケア応用　特集Ⅱ：電子回路関連技術

本誌掲載ページ: 344-352 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/144/4/144_344/_article/-char/ja/
