電圧形PWMインバータを用いた直流試験による回転機の特性算出法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2011/11/01

タイトル(英語): Determination of Rotational-Machine Characteristics by Performing DC Tests using Voltage-Source PWM Inverter

著者名: 山本　修（職業能力開発総合大学校），小山　孝（（株）明電舎），荒　隆裕（職業能力開発総合大学校）

著者名(英語): Shu Yamamoto (Polytechnic University), Takashi Oyama (MEIDENSHA CORPORATION), Takahiro Ara (Polytechnic University)

キーワード: 直流試験，静止試験，回転機，インバータ，演算子インピーダンス，磁気飽和　　DC test，standstill test，rotational machine，inverter，operational impedance，magnetic saturation

要約(英語): The DC tests can predict the operational impedance of rotational machines by a simple standstill test. This paper presents a new DC test using a voltage-source PWM inverter, which does not require a specially assembled DC-power-source unit that is required to perform conventional DC tests. In this paper, three DC tests (DC decay, step response method, and pulse response methods) using the inverter as a power source are discussed. These tests are performed on an air-core reactor and 5.5kW semi-closed squirrel-cage induction machine to verify their validity. In addition, the authors propose an improved DC decay test that can consider the magnetic saturation of the main flux; this test is referred to as the two-step-voltage DC decay test. This test is also carried out on the tested induction machine. Using the test results, the authors demonstrate the calculation of not only no-load saturation performance by considering the magnetic saturation flux but also the starting performance. By comparing between these calculation results and actual measurement data, the authors validate the proposed two-step-voltage DC decay test.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.131 No.11 （2011） 特集：回転機技術

本誌掲載ページ: 1292-1300 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/131/11/131_11_1292/_article/-char/ja/
