永久磁石同期モータの小形化を目的とした熱-磁界連成最適設計法の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2011/11/01

タイトル(英語): Development of Optimal Design Method with Thermo-Magnetic Field Coupling Analysis for Miniaturization of Permanent-Magnet Synchronous Motors

著者名: 北村　英樹（（株）日立製作所 日立研究所），岩崎　則久（（株）日立製作所 日立研究所），北村　正司（（株）日立製作所 日立研究所），森　英明（（株）日立製作所 機械研究所），山崎　政英（（株）日立産機システム 習志野事業所），二瓶　秀樹（（株）日立産機システム 習志野事業所）

著者名(英語): Hideki Kitamura (Hitachi Research laboratory, Hitachi, Ltd.), Norihisa Iwasaki (Hitachi Research laboratory, Hitachi, Ltd.), Masashi Kitamura (Hitachi Research laboratory, Hitachi, Ltd.), Hideaki Mori (Mechanical Engineering Research laboratory, Hitachi, Ltd.), Masahide Yamasaki (Hitachi Industrial Equipment Systems Co., Ltd.), Hideki Nihei (Hitachi Industrial Equipment Systems Co., Ltd.)

キーワード: 永久磁石同期モータ，小形化，熱―磁界連成解析，最適化，Rosenbrock法　　permanent-magnet synchronous motor，miniaturization，thermo-magnetic field coupling analysis，optimization，Rosenbrock's method

要約(英語): A straightforward solution for minimizing the cost of major materials used in motors, such as permanent magnets and silicon steel sheets, is to reduce the motor size as far as possible. However, there is a trade-off between the motor size and temperature rise in the motor that should be taken into account while reducing the motor size. For achieving this, we have been developing an optimal design method based on a combination of a thermo-magnetic field coupling analysis and a direct search algorithm. This paper reports the details of this design method. An outer-rotor, multipole permanent-magnet synchronous motor is the test motor. The results of the torque-density-maximization problem involving constraints on the terminal voltage, coil-temperature rise, and demagnetization of the magnet are shown. The usefulness of our method is also demonstrated.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.131 No.11 （2011） 特集：回転機技術

本誌掲載ページ: 1301-1308 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/131/11/131_11_1301/_article/-char/ja/
