逆相電流の直接検出による誘導機の固定子巻線の短絡故障診断法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2011/11/01

タイトル(英語): Diagnosis of Stator-Winding-Turn Faults of Induction Motor by Direct Detection of Negative-Sequence Currents

著者名: 加藤　利次（同志社大学 理工学部 電気工学科），井上　馨（同志社大学 理工学部 電気工学科），吉田　圭亮（同志社大学 理工学部 電気工学科）

著者名(英語): Toshiji Kato (Dept. of Electrical Engineering, Doshisha University), Kaoru Inoue (Dept. of Electrical Engineering, Doshisha University), Keisuke Yoshida (Dept. of Electrical Engineering, Doshisha University)

キーワード: 誘導機，固定子巻線故障，故障診断，逆相電流，最小二乗フィッティング，dSPACE　　induction motor，stator turn winding，fault diagnostics，negative sequence current，LS fitting，dSPACE

要約(英語): In an AC motor, the quick detection of an initially small fault is important for preventing any consequent large fault. Various detection approaches have been proposed in previous papers, for example, by the Park vector (PV), AI techniques, wavelet analysis, and negative-sequence analysis. This paper proposes a method for diagnosing the stator-winding faults of an induction motor by the direct detection of its negative-sequence current. Before starting the diagnosis, the asymmetry admittances for the considered fault cases are obtained by analysis or simulation. The amplitude and phase of the positive-sequence voltage, Vp, and of the positive-sequence current, Ip, are extracted from the voltage PV and current PV, respectively. The amplitude and phase of the negative-sequence, In, are extracted from the residue. The asymmetry admittance, Ya, is calculated from In and Vp. When the positive-sequence admittance is known, Ya can also be calculated from Yp, Ip, and In. These steps are repeated for each sample time and the motor condition is diagnosed according to the variations in the Ya values. The simulation and experimental results are also shown and the proposed method is investigated and validated.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.131 No.11 （2011） 特集：回転機技術

本誌掲載ページ: 1346-1353 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/131/11/131_11_1346/_article/-char/ja/
