正弦波PWMインバータのロバスト制御器設計

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/12/01

タイトル(英語): Robust Controller Design for Sinusoidal PWM Inverters

著者名: 若佐　裕治（山口大学大学院理工学研究科），馬場　雄介（山口大学大学院理工学研究科），田中　俊彦（山口大学大学院理工学研究科），田中　幹也（山口大学大学院理工学研究科）

著者名(英語): Yuji Wakasa (Graduate School of Science and Engineering, Yamaguchi University), Yusuke Baba (Graduate School of Science and Engineering, Yamaguchi University), Toshihiko Tanaka (Graduate School of Science and Engineering, Yamaguchi University), Kanya Tanaka (Graduate School of Science and Engineering, Yamaguchi University)

キーワード: PWMインバータ，ロバスト制御，線形行列不等式，内部モデル原理　　PWM inverter，robust control，linear matrix inequality，internal model principle

要約(英語): This paper proposes a robust controller for sinusoidal PWM inverters, which can track a sinusoidal reference with zero steady-state error. A closed-loop system for single-phase full-bridge inverters is constructed on the basis of the internal model principle. The appropriate control gains of the constructed closed-loop system are determined using a state-feedback controller design method via linear matrix inequalities. The proposed controller can adapt to the uncertain variations in the load conditions. It is also shown that the pole-placement constraints and control performance indexes based on the H2 and H∞ norms as well as a standard quadric performance index in optimal control can be applied to the proposed robust controller. Digital computer simulation is implemented to confirm the validity of the proposed robust controller with the internal model principle. A prototype experimental model is constructed and tested. Experimental results demonstrate that an excellent and practical robust controller for sinusoidal PWM inverters is realized under uncertain and fluctuating load conditions, including the nonlinear loads such as diode rectifiers.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.12 （2012）

本誌掲載ページ: 1104-1111 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/12/132_1104/_article/-char/ja/
