磁気軸受の周波数特性解析と制御系設計への適用

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/12/01

タイトル(英語): Frequency Domain Analysis of Magnetic Bearings and Its Application to the Design of Controllers

著者名: 澤田　正志（川崎重工業（株）明石工場），田宮　智彰（川崎重工業（株）明石工場），植木　允啓（川崎重工業（株）明石工場），中島　健一（川崎重工業（株）明石工場），片岡　幹彦（川崎重工業（株）明石工場），黒田　雅教（川崎重工業（株）明石工場），進藤　裕司（川崎重工業（株）明石工場）

著者名(英語): Masashi Sawada (Akashi works, Kawasaki Heavy Industries, Ltd.), Tomoaki Tamiya (Akashi works, Kawasaki Heavy Industries, Ltd.), Masahiro Ueki (Akashi works, Kawasaki Heavy Industries, Ltd.), Ken-ichi Nakashima (Akashi works, Kawasaki Heavy Industries, Ltd.), Mikihiko Kataoka (Akashi works, Kawasaki Heavy Industries, Ltd.), Masanori Kuroda (Akashi works, Kawasaki Heavy Industries, Ltd.), Yuji Shindo (Akashi works, Kawasaki Heavy Industries, Ltd.)

キーワード: 磁気軸受，周波数特性，分布系，遅れ時間，有限要素解析　　magnetic bearing，frequency response，distributed system，delay time，finite element analysis

要約(英語): This paper proposes a method to derive the frequency response of an actuator with a solid iron core. This actuator is designed for a thrust magnet bearing of a high-speed motor. The actuator is treated as a distributed system with eddy currents in the solid iron core. Theoretical formulation of the frequency response is derived by using Maxwell's equations and by using a simple magnetic circuit model. The finite element analysis results and the experimental results are also obtained. A method for obtaining the rational expression of the frequency response is derived. Although the method is essentially based on a least-square method, it is modified to some extent in order to obtain a rational expression. By using this rational expression, we show that the controller for the magnetic bearings can be designed with usable accuracy, before manufacturing the actual actuator.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.12 （2012）

本誌掲載ページ: 1131-1140 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/12/132_1131/_article/-char/ja/
