アクティブバッファを用いた単相降圧形PFC整流器の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2013/02/01

タイトル(英語): Development of Buck PFC AC-DC Converter using an Active Buffer

著者名: 大沼　喜也（長岡技術科学大学），伊東　淳一（長岡技術科学大学）

著者名(英語): Yoshiya Ohnuma (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

キーワード: 単相整流器，力率改善，降圧形，リプル電力，エネルギー蓄積要素　　single-phase rectifier，power factor correction，buck type，ripple energy，energy storage device

要約(英語): This paper discusses a new circuit configuration and a control method for a single-phase AC-DC converter with power factor correction (PFC). The proposed converter can achieve low total harmonic distortion (THD) for the input current, and at the same time, it can use an active buffer to control the low output DC voltage ripple. The proposed converter does not require large smoothing capacitors and large inductors, which are conventionally required in such converters to decouple the power ripple with a frequency twice that of the power supply. The buffering energy is maintained by a small capacitor, which controls the voltage variation in the capacitor using the active buffer. In this paper, the fundamental operations of the proposed converter are confirmed by experimental results. From the experimental results, it is found that the input current THD is 1.44%, the ratio of the output voltage ripple is 6.33% and the input power factor (PF) is greater than 99%. In addition, a maximum efficiency greater than 96% is obtained in the prototype.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.133 No.2 （2013） 特集：Okinawa型ロボット・組み込みシステム

本誌掲載ページ: 188-195 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/133/2/133_188/_article/-char/ja/
