太陽光発電システム用絶縁型DC-DCコンバータの軽負荷時高効率制御法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2013/02/01

タイトル(英語): High Efficiency Control Method for Insulated DC-DC Converter under Light Load Condition for Photovoltaic Generation System

著者名: 寺江　悠太（長岡技術科学大学 電気系），安瀬　翔平（長岡技術科学大学 電気系），大石　潔（長岡技術科学大学 電気系），芳賀　仁（長岡技術科学大学 電気系），清水　隆之（シャープ新潟電子工業（株））

著者名(英語): Yuta Terae (Department of Electrical Engineering, Nagaoka University of Technology), Shohei Anze (Department of Electrical Engineering, Nagaoka University of Technology), Kiyoshi Ohishi (Department of Electrical Engineering, Nagaoka University of Technology), Hitoshi Haga (Department of Electrical Engineering, Nagaoka University of Technology), Takayuki Shimizu (Department of Electrical Engineering, SHARP Niigata Electronics Corp.)

キーワード: 系統連系太陽光発電システム，絶縁型DC-DCコンバータ，位相シフトインバータ，周波数制御，ソフトスイッチング　　Grid-connected Photovoltaic generation system，insulated DC-DC converter，phase shift inverter，frequency control，soft-switching

要約(英語): This paper proposes a high-efficiency control method for an insulated DC-DC converter with a phase-shift inverter for a single-phase grid-connected photovoltaic generation system. The proposed control method for the inverter output power is regulated by controlling each phase angle of the inverter leg and by controlling the frequency. Moreover, the inverter switching frequency is controlled by changing the input current of the main circuit, and soft-switching can be realized by controlling the frequency. The phase angle of the inverter is controlled by the output voltage of the main circuit. The validity of the proposed method is confirmed via the experimental results. Using the proposed method, we find the efficiency that improved by a maximum of 3.6% as compared with the case of the conventional method.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.133 No.2 （2013） 特集：Okinawa型ロボット・組み込みシステム

本誌掲載ページ: 196-202 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/133/2/133_196/_article/-char/ja/
