磁気飽和の影響を考慮した直流試験による同期機の同期リアクタンスおよび無負荷飽和曲線の算出法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2013/02/01

タイトル(英語): Determination of Synchronous Reactance and No-load Saturation Curve of Synchronous Machines by DC Test Considering Magnetic Saturation Effect

著者名: 山本　修（職業能力開発総合大学校），平原　英明（職業能力開発総合大学校），田中　晃（職業能力開発総合大学校），荒　隆裕（職業能力開発総合大学校）

著者名(英語): Shu Yamamoto (Polytechnic University), Hideaki Hirahara (Polytechnic University), Akira Tanaka (Polytechnic University), Takahiro Ara (Polytechnic University)

キーワード: 同期機，直軸同期リアクタンス，横軸同期リアクタンス，無負荷飽和曲線，直流試験，磁気飽和　　synchronous machine，d-axis synchronous reactance，q-axis synchronous reactance，no-load saturation curve，DC test，magnetic saturation

要約(英語): DC tests can accurately determine the unsaturated synchronous machine equivalent circuit constants by a simple standstill test. This paper presents two improved DC tests that account for the magnetic saturation of the stator iron core by the main flux. These tests are tentatively named Step Response Test (I) and Step Response Test (II). The former can predict the incremental d-axis synchronous reactance by performing a Fourier transform of the voltage and current measured when a small step voltage is applied to the two armature terminals as a field current flows. The latter can determine the incremental d- and q-axes synchronous reactances by the same Fourier transform of the voltage and current measured when a small step voltage is applied to the two armature terminals as an armature current flows. In addition, this paper introduces a new method to calculate not only the static d- and q-axes synchronous reactances but also the no-load saturation and short-circuit characteristic curves. This new method does not require the results from any additional tests including the rotational driving tests and dimensional information, which can only be obtained from the manufacturer. To demonstrate the validity of the proposed method, results of an experiment using 10-kVA laminated synchronous machines with damper winding are presented.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.133 No.2 （2013） 特集：Okinawa型ロボット・組み込みシステム

本誌掲載ページ: 214-221 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/133/2/133_214/_article/-char/ja/
